Lenze · E84AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 10/2013 · TD17 159
14 Implemented CIP™ objects
14.4 Lenze objects
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
14.4.4 Lenze Class (110 / 0x6E)
The "Lenze Class (110 / 0x6E)" enables read or write access to Lenze codes.
The Lenze code must be specified as an "instance" (corresponding code no. 1 ... 65535) and its
subcodes must be specified as "attributes".
Class attributes
Instance attributes
Supported service codes
 Note!
• If the corresponding Lenze code does not have a subcode, the value '0' must be
entered in the attribute. If '0' is not supported as attribute value by the engineering
tool used, the value '1' must be entered.
• A display code cannot be configured using "Set_Attribute_Single".
Attribute
ID
Service Name Data type Value
1 Get Revision UINT 2 (0x0002)
2 Get Max. Instance UINT 1 (0x0001)
Attribute
ID
Service Name Data type Value
0 ... 255 Get / Set Lenze Subcode number Data type of
the subcode
Value of the subcode
Service code Name Description
0x0E Get_Attribute_Single Outputs the value of a certain attribute.
0x10 Set_Attribute_Single Changes the value of a certain attribute.
