Lenze · E84AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 10/2013 · TD17 117
13 Parameter reference
13.1 Parameters of the communication module
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13862
C13863
C13870
Parameter | Name:
C13862 | CIP Network Status
Data type: UNSIGNED_16
Index: 10713 = 0x29D9
Display of the current CIP network status
• The status is also indicated via the NS LED.
LED status displays
( 89)
Selection list (read only)
0 No IP Address
1 Nonexistent
2 Established
3 Timed Out
4 Duplicate IP
5 Self-Test
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13863 | Ethernet Port
Data type: UNSIGNED_16
Index: 10712 = 0x29D8
Display of the baud rate currently used on the Ethernet connections
Selection list (read only)
0 Nonexistent
1 10 Mbps/Half Duplex
2 10 Mbps/Full Duplex
3 100 Mbps/Half Duplex
4 100 Mbps/Full Duplex
5 Reserved
6 Reserved
Subcodes Info
C13863/1 Ethernet port X259 link state
C13863/2 Ethernet port X260 link state
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13870 | CIP Connections State
Data type: UNSIGNED_16
Index: 10705 = 0x29D1
Display of the current CIP connection status
Selection list (read only)
0 Nonexistent
3 Established
4 Timed Out
Subcodes Info
C13870/1 Status of CIP connection 1
... ...
C13870/8 Status of CIP connection 8
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
