13 Parameter reference
13.1 Parameters of the communication module
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13874
C13875
C13880
Parameter | Name:
C13874 | CIP Connections Timeout Time
Data type: UNSIGNED_32
Index: 10701 = 0x29CD
Display of the timeouts (ms) of the CIP connections
Display range (min. value | unit | max. value)
0 ms 4294967295
Subcodes Info
C13874/1 Timeout time of CIP connection 1
... ...
C13874/8 Timeout time of CIP connection 8
Read access Write access CINH PLC STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13875 | CIP Connections RUN/IDLE Flag
Data type: UNSIGNED_16
Index: 10700 = 0x29CC
Display of the run and idle flags of the CIP connections
Selection list (read only)
0 Nonexistent
1 IDLE
2 RUN
Subcodes Info
C13875/1 RUN/IDLE flag - CIP connection 1
... ...
C13875/8 RUN/IDLE flag - CIP connection 8
Read access Write access CINH PLC STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13880 | Monitoring Reaction
Data type: UNSIGNED_8
Index: 10695 = 0x29C7
Setting of the monitoring response in the event of a Fault with regard to EtherNet/IP communication ( 88)
(Mapping of the Lenze object Lenze Class (101 / 0x65)
( 155))
A change in the monitoring response becomes immediately effective.
Selection list
0 No response
1Fault
3 Quick stop by trouble
4 Warning Locked
6 Information
Subcodes Lenze setting Info
C13880/1 0: No Response Idle Mode
C13880/2 3: Quick stop by trouble Fault Mode
(only for "exclusive owner" connections)
C13880/3 0: No Response Expl. message timeout
C13880/4 0: No Response Overall Ethernet communication timeout
Read access Write access CINH PLC STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
