• Additional information is displayed according to the following priority list:
Priority Display Meaning
1 GLOBAL DRIVE INIT Initialising or communication error between operating module and controller
2 XXX - TRIP Active TRIP (contents of C0168/1)
3 XXX - MESSAGE Active message (contents of C0168/1)
4
Special controller states:
Switch-on inhibit
5
Source for controller inhibit (the value of C0004 is displayed at the same time):
STP1 Te rmina l X5/ 28
STP3 Operating module or LECOM A/B/LI
STP4 INTERBUS or PROFIBUS
STP5 System bus (CAN)
STP6 C0040
6
Source of quick stop:
QSP-term-Ext HIGH signal is applied at input MCTRL-QSP on the function block MCTRL
(in factory setting applied to terminals X5/E1 and X5/E2)
QSP-C0135 Operating module or LECOM A/B/LI
QSP-AIF INTERBUS or PROFIBUS
QSP-CAN System bus (CAN)
7 XXX - WARNING Active warning (contents of C0168/1)
8 xxxx Value under C0004
User menu
In some applications, specific codes must be changed more often.
You can therefore establish a menu with max. 32 codes which you use frequently under C0517.
• The number before the comma is the code number.
• The number after the comma is the subcode.
• Code-subcode combinations are allowed only once.
5.6.2 Parameter change
Tip!
You have to save the changed parameter, if you do not want to loose the modifications after mains
disconnection (see chapter 5.6.3).
Basic procedure
1. Change to the code level from the menus using the arrow keys
_, `, ] or [
”Code” is displayed.
2. Select code or subcode with
_ or `.
3. Change to the parameter level using PRG. ”Para” is displayed.
4. Move the cursor (small, black bar) under the number to be changed with
] or [.
5. Change number with
_ or `.
6. Repeat 4. and 5. to change other numbers, if necessary.
7. Accept parameters. The way the controller accepts the modified parameters is shown in the
LCD display in front of the parameter:
