Commissioning
5-11
L MA9300PLC EN 1.4
Segments and status indications of the LCD display:
Segment Explanation
Code number Four-digit code number
Subcode number Two-digit subcode number
Parame te r Parameter value with max. twelve digits
Te xt Help text with max. 13 digits;
in the operating level: status information of C0183 or contents of C0004
SH PRG p
SH PRG p: Parameter is accepted only with SHIFT + PRG (OFFLINE)
SH PRG: Parameter is accepted only with SHIFT + PRG during controller inhibit (OFFLINE)
p : Parameter is immediately accepted by the controller (ONLINE)
empty: Parameter cannot be changed
Active level Menu = Menu level, Code = Code level, Para = Parameter level, no display = operating level
Status indications of the keypad
Display on off
RDY Ready for operation Initialization or error
IMP Power outputs inhibited Power outputs enabled
FAIL Active fault No fault
I
MAX
Motor current setpoint ≥ C0022 Motor current setpoint < C0022
M
MAX
Speed controller 1 in its limitation
Drive torque-controlled.
Drive speed-controlled
Key functions
”SHIFT + ” means: Press SHIFT and the second key indicated at the same time.
Keys
Function
Menu level Code level Parameter level/operating level
PRG - Change between code, parameter and operating level
SHIFT + PRG - - Accept parameters (depending on the
parameter and menu)
_ Next higher menu item Next higher code number Increase displayed number
SHIFT + _ Next higher menu item fast Increase code number fast Increase displayed number fast
` Next lower menu item Next lower code number Decrease displayed number
SHIFT + ` Next lower menu item fast Decrease code number fast Decrease displayed number fast
] Next higher menu level Go to the menu level Cursor to the left
[ Next lower menu level (submenus) or code
level
- Cursor to the right
RUN Cancel function of the STOP key
STOP Inhibit controller: Quick stop, controller inhibit or switched off C0469
Trip reset: When a trip has occurred and the STOP key is pressed (independently of C0469).
Then, press RUN.
The LED in the key shows the status of the STOP key:
• LED on: STOP key pressed
• LED off: RUN key pressed
Operating level
From the parameter level, you reach the operating level by pressing PRG.
• In the operating level, additional status information or the additional display value specified
under C0004 is displayed (presetting: actual speed C0051).
– When selecting the USER menu, the first code level of the USER menu is displayed in the
first line.
