8
Mechanical installaon
Operang Instrucons i410-Cabinet
B
H1
H
E2
E1
X
H Device height X: Number of top/boom xings
B Device width (lower fastening not visible)
T Device depth E1: Top mounng clearance
H1 Hole dimension for top/boom xing E2: Boom mounng clearance
4 Mechanicalinstallaon
4.1 Dimensions and assembly
Rated power
[kW]
Weight
[kg]
H
[mm]
W
[mm]
D
[mm]
H1
[mm]
X [screws + hole
spacing]
E1
[mm]
E2
[mm]
1-phasemainsconnecon230/240V;withintegratedRFIlter
I41AExxxB 0.25 – 0.37 0.75 155 60 130 165 1 - M5 50 50
I41AExxxB 0.75 0.95 180 60 130 190 1 - M5 50 50
I41AExxxB 1.1 – 2.2 1.35 250 60 130 260 1 - M5 50 50
