4.3.3 List of AOI Inputs and Outputs (Message Handler)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.3.3 List of AOI Inputs and Outputs (Message Handler)
Inputs
Identifier
Data type
Information/possible settings
xSend
BOOL
Send messages.
diActivateNetworkControl
DINT
P400:37 – Setting value [1] for Constant TRUE is required for
network control.
diEnableInverter
DINT
P400:1 – Set value to [1] for Constant TRUE. This bypasses the
need for a hardware enable signal.
diRun
DINT
P400:2 – Setting value [1] for Constant TRUE is recommended for
network control.
diSetpointSource
DINT
P201:1 – Setting value [5] for Network is required for network
control.
diMainsVoltage
DINT
P208:1 – 230 V [0], 400 V [1], 480 V [2]
diMotorRatedRPM
DINT
P320:4 – [RPM]
rMotorRatedCurrent
REAL
P323 – [Amps]
rMotorRatedFrequency
REAL
P320:5 – [Hz]
rAccelTime
REAL
P220 – Accel time [seconds]
rDecelTime
REAL
P221 – Decel time [seconds]
rQspDecelTime
REAL
P225 – Quickstop decel time [seconds]
Outputs
Identifier
Data type
Value/meaning
Value_Out
BOOL
Value being sent to i550 parameter
xDone
BOOL
All messages sent.
In/out
Identifier
Data type
Value/meaning
MSG_Out
MESSAGE
Reference to external MSG instruction
