Lenze Smart Motor m300 MSEMA Series - Controlling the Drive

Commissioning
Controlling the drive
5
EN
44
Lenze ¯ MDKSEMA ¯ 5.0
Device data
Parameter Value
Comment
Name Delivery Setting range
Material number
Order−related
[number]
Drive identification
Device type [text]
Firmware version [text]
Hardware Version [text]
Motor [text]
Gearboxes [text]
Ratio [number]
Brake [text]
Serial number [text]
5.3 Controlling the drive
Activating speeds
Output speed
Output speed activation
Status message
Values Direction of rotation X1.4
(DI1)
X1.2
(DI2)
X2.2
(DI3)
X2.4
(DO1)
Status
CCW STOP CW
1
Order−related
setting
< 0 r/min 0 r/min > 0 r/min
LOW LOW LOW
2 HIGH LOW LOW
3 LOW HIGH LOW
4 HIGH HIGH LOW
5 LOW/HIGH LOW/HIGH HIGH
LOW Not ready for
operation
HIGH Ready for operation
