Lenze TML User Manual

Lenze 13466187 EDBTL03 v8 EN, DE, FR, IT, ES 17
Commissioning
Code Possible Settings
IMPORTANT
No. Name Lenze Selection
C77
I
max
gain
0.25
0.00 16.0 For most applications, there is no need
to change the Lenze settings
(1)
C78
Integral action time
65
12 {ms} 9990
C84
Motor stator
resistance
0.00
0.00 {W} 64.0 Will be automatically programmed
by c48
(1)
C86
Motor rated power 0.00 {kW} 99.9 • Set to motor nameplate kW
• Lenze setting = Tml rated kW
C87
Motor rated speed
1390
300 {RPM} 65000 Set to motor nameplate speed
C88
Motor rated current
0.0
0.0 {A} 480 Set to motor nameplate current
C89
Motor rated
frequency
50
10 {Hz} 999 Set to motor nameplate frequency
C90
Motor rated voltage
0
0 {V} 600 Set to motor nameplate voltage
C91
Motor cosine phi
0.80
0.40 1.00 Set to motor power factor
Note
If motor power factor is not known, use the following formulas:
cosphi=motorWatts/(motorefciencyXC90XC88X1.732)
cos phi = cos [ sin
-1
(magnetizing current / motor current) ]
C92
Motor stator
inductance
0.0
0.0 {mH} 2000
Will be automatically programmed
by c48
(1)
C93
Driveidentication
• Indicates controller rating,
format: x.yz, or x.y.z
• x. = voltage (2. = 200/240V, 1~)
• yz or y.z = kW rating
• Example:
• 2.0.3 = 200/240 V, 1~, 0.37 kW
C94
User password
0
0 999
Changingfrom“0”(nopassword),valuewill
start at 763
When set to a value other than
0, must enter password at C00 to
access parameters
C99
Software version
Display, format: x.yz
c01
Acceleration time 2
5.0
0.0 {s} 999 • Activated using CE1...CE3
• c01 = frequency change
0 Hz...C11
• c03 = frequency change
C11...0 Hz
• For S-ramp accel/decel, adjust c82
c03
Deceleration time 2
5.0
0.0 {s} 999
c06
Holding time -
automatic DC injection
brake (Auto-DCB)
0.0
0.0 {s} 999
0.0 = not active
999 = continuous brake
• Automatic motor braking after StP
by means of motor DC current for
the entire holding time (afterwards:
U, V, W inhibited)
• Conrmmotorsuitabilityforusewith
DC braking
(1) Changing these settings can adversely affect performance. Contact Lenze technical support prior to changing.
