Rev. 03 - 07/2015 - Cod. 1501151 - Instruction manual for vacuum chamber packaging machines Mod. C254-C308-C312-C412-C420

Switchthemachineoffusingmainswitchandremovetheplug.
RemovethePEllersfromthevacuumchamber andlowerthelidtotherestingposition.
Uninstallthebackpanel.UnscrewthescrewsusingaPhillipsheadscrewdriver.
Liftthemachinebodyusingbothhandsandlayitonthefront(ontheworktable),restingitononeofthe
surfacessupplied
A
inordertoavoiddamagingthemainswitch.
Locationofthemaincomponents
insidethemachine
A
Three-way solenoid valvefor
liftingthesealingbar

Two-way solenoidvalvefor di-
scharge
C
 Protectivelidforthepowerboard
D
 Flatconnectioncable,powerbo-
ard-controlboard
E
 Vacuumpump
F
 Two-waysolenoidvalveforgas
injection
G
 Aircylinderforliftingthebar
H
 Protectivelidforthecontrolboard
I
Sealing transformer
J
 Powersupplycable
K
 Gasspring
Toclose,lowerthecasingonthe
base,making suretoverify the
correctpositioningofthemachine
bodyaswellasthepositionofthe
cablesand hosesthatcould be
cutor damagedby themachine
panels.
Re-installthebackpanel.
