Toreachthepumpformaintenance,followtheprocedure
describedinchap.11.2
Locatethepumpintakeblockonwhichisfastenedthetran-
sparentpipewithmetalcoil
A
,thatconnectsthepumpto
thevacuumchamber.
Usingasetscrewwrenchtoundothetwoscrewfastenerson
theblock.Lifttheintakeblock.
Removersttherubbershutterandthenthesteelone.Check
theconditionoftheaccessibleintakesectionandcleanitif
necessarywithaclothsoakedinalcohol.
PutinthenewrubberandsteelshuttersF.
PuttheintakeblockbackinplaceandfastenthetwoscrewsF.
Downandclosethemachineasdescribedinchap.11.2
