Device description
Leuze electronic MLC 530 11
3 Device description
The safety sensors from the MLC 500 series are active opto-electronic protective devices. They satisfy the
following standards:
The safety sensor consists of a transmitter and a receiver (see figure 3.1). It is protected against over-
voltage and overcurrent acc. to IEC 60204-1 (safety class 3). Its infrared beams are not influenced by
ambient light (e.g. welding sparks, warning lights).
3.1 Device overview
The series is characterized by three different receiver classes (Basic, Standard, Extended) with certain
features and properties (see table 3.1).
Table 3.1: Device models in the series with specific features and functions
Protective field properties
The beam distance and the number of beams are dependent on the resolution and protective field height.
MLC 500
Type in accordance with EN IEC 61496 4
Category in accordance with EN ISO 13849 4
Performance Level (PL) in accordance with EN ISO 13849-1 e
Safety Integrity Level (SIL) in accordance with IEC 61508 and SILCL in
accordance with EN IEC 62061
3
Transmitter Receivers
Basic Standard Extended
MLC 500
MLC 501
MLC 510
MLC 511
MLC 520 MLC 530
OSSDs (2x)

Transmission channel changeover

LED display

7-segment display

Automatic start/restart

RES

EDM

Linkage

Blanking

Muting

Scan mode

Range reduction

Depending on the resolution, the effective protective field height can be larger than the optically
active area of the safety sensor housed in yellow (see figure 3.1 and see figure 14.1).
