Technical data
Leuze electronic MLC 530 88
Table 14.8: Additional dimensions for calculating the effective protective field height
14.3 Dimensional drawings: accessories
Figure 14.2: BT-L mounting bracket
Figure 14.3: BT-Z parallel bracket
The specified response times apply for operating modes 1, 2 and 3 (function group FG2). In op-
erating mode 3 (function group FG1, DoubleScan), the specified value doubles. In operating
modes 4 and 6 (MaxiScan), the response time always has a fixed value: 100 ms.
R = resolution B C
14 mm 0 mm 52 mm
20 mm 1.5 mm 48 mm
30 mm 13 mm 49 mm
40 mm 19 mm 43 mm
90 mm 44 mm 18 mm
39
16
29
12
R10
R3.1
4
R6
R3.1
R10
30
12
R3.1
18.4
31.7
73
61
6.2
6.2
R3.1
R10
R10
22
10
R3.1
10.8
4
25
12.1
