Calculation of the effective protective field height
H
PFE
[mm] = Effective protective field height
H
PFN
[mm] = Nominal protective field height (see table 14.7); this corresponds to the length of the
yellow housing part
A [mm] = Total height
B [mm] = Additional dimensions for calculation of the effective protective field height (see
table 14.8)
C [mm] = Value for calculating the effective protective field height (see table 14.8)
Table 14.7: Dimensions (nominal protective field height), weight and response time for operating
modes 1, 2 and 3 (function group FG2)
Device type Transmitter and receiver Receivers
Dimensions [mm] Weight [kg] Response time [ms] acc. to resolution
Type
H
PFN
a)
A=H
PFN
+66
b)
14 mm 20 mm 30 mm 40 mm 90 mm
MLC…-150 150 216 0.30 5 4 3 3 -
MLC…-225 225 291 0.37 - 5 3 3 -
MLC…-300 300 366 0.45 8 7 4 4 -
MLC…-450 450 516 0.60 11 9 5 5 3
MLC…-600 600 666 0.75 14 12 7 7 3
MLC…-750 750 816 0.90 17 14 8 8 4
MLC…-900 900 966 1.05 20 17 9 9 4
MLC…-1050 1050 1116 1.20 23 19 10 10 4
MLC…-1200 1200 1266 1.35 26 22 12 12 5
MLC…-1350 1350 1416 1.50 30 24 13 13 5
MLC…-1500 1500 1566 1.65 33 26 14 14 6
MLC…-1650 1650 1716 1.80 36 29 15 15 6
MLC…-1800 1800 1866 1.95 39 31 17 17 7
MLC…-1950 1950 2016 2.10 42 34 18 18 7
MLC…-2100 2100 2166 2.25 45 36 19 19 7
MLC…-2250 2250 2316 2.40 48 39 20 20 8
MLC…-2400 2400 2466 2.55 51 41 22 22 8
MLC…-2550 2550 2616 2.70 55 44 23 23 9
MLC…-2700 2700 2766 2.85 58 46 24 24 9
MLC…-2850 2850 2916 3.00 61 49 25 25 9
MLC…-3000 3000 3066 3.15 64 51 26 26 10
a) H
PFN
= nominal protective field height = length of the yellow housing part
b) Total height, see figure 14.1
