Ordering information and accessories
Leuze electronic MLC 530 91
15 Ordering information and accessories
Nomenclature
Part description:
MLCxyy-za-hhhh
Table 15.1: Article list
Table 15.2: Part descriptions, examples
Scope of delivery
• Transmitter including 2 sliding blocks, 1 instruction sheet
• Receiver incl. 2 sliding blocks, 1 self-adhesive notice sign “Important notices and notices for the
machine operator”, 1 connecting and operating instructions (PDF file on CD-ROM)
Table 15.3: Article numbers of MLC 500 transmitter depending on resolution and protective field
height
MLC Safety sensor
x Series: 5 for MLC 500
yy Function classes:
00: Transmitter
30: Extended receiver - blanking/muting
z Device type:
T: transmitter
R: receiver
a Resolution:
14: 14 mm
20: 20 mm
30: 30 mm
40: 40 mm
90: 90 mm
hhhh Protective field height:
150 … 3000: from 150 mm to 3000 mm
Examples for part de-
scription
Features
MLC500T14-600 Type 4 transmitter, PL e, SIL 3, resolution 14 mm, protective field height
600 mm
MLC500T30-900 Type 4 transmitter, PL e, SIL 3, resolution 30 mm, protective field height
900 mm
MLC530T90-1500 Type 4 Extended receiver, PL e, SIL 3, resolution 90 mm, protective field height
1500 mm
Protective
field height
hhhh [mm]
14 mm
MLC500T14-
hhhh
20 mm
MLC500T20-
hhhh
30 mm
MLC500T30-
hhhh
40 mm
MLC500T40-
hhhh
90 mm
MLC500T90-
hhhh
150 68000101 68000201 68000301 68000401 -
225 - 68000202 68000302 68000402 -
300 68000103 68000203 68000303 68000403 -
450 68000104 68000204 68000304 68000404 68000904
