Device description
Leuze electronic BPS 300i 18
Display functions
The following functions can be displayed and activated in the display:
• Position value
•
Position Value
• Position value in mm
Display with . as decimal separator character (e.g.,
+ 34598.7 mm
)
• Read quality
•
Quality
• 0 … 100 %
• Device status
•
BPS Info
•
System OK
/
Warning
/
Error
• I/O status
Status of the inputs/outputs
•
I/O status
•
IO1 In:0
/
IO2 Out:0
In/Out depending on configuration, 0/1 for state of the I/O
• Transmission standard of the serial interface
• Interface
• RS 232/RS 422
• Version information
Software and hardware version of the device
•
Version
•
SW: V1.3.0 HW:1
The display is controlled via the control buttons:
• –
Enter: activate or deactivate the display shift function
• –
Down: scroll through functions (downwards)
Example: Representation of the I/O status on the display
1. Press button : display flashes
2. Press button : Display changes from position value (
Position Value
) to read quality (
Quality
)
3. Press button : Display changes from read quality (
Quality
) to device status (
BPS Info
)
4. Press button : Display changes from device status (
BPS Info
) to I/O status
5. Press button : I/O status displayed, display stops flashing
Display during device start-up
During device start-up, a start-up display first appears which is briefly followed by the display with the
version information.
The standard display after starting up the BPS is
Position Value
.
NOTICE
Laser activation by selecting
Quality
!
If measurement is stopped, the laser is activated by selecting
Quality
.
