Leuze BPS 300i - Bar Code Tape

Specifications
Leuze electronic BPS 300i 74
Table 13.10: Ambient temperature
13.2 Bar code tape
Table 13.11: BCB dimensions
Table 13.12: BCB structure
Table 13.13: BCB environmental data
Ambient temperature (operation) -35 °C … +50 °C
Ambient temperature (storage) -35 °C … +70 °C
BCB BCB8
Grid 40 mm 30 mm
Standard height 47 mm 47 mm
Preferred heights 25 mm,
Special heights for lengths
greater than 150 m
25 mm, 30 mm, special
heights for lengths greater
than 150 m
Length 0 … 5 m, 0 … 10 m,
0 … 20 m, …,0 … 150 m,
0 … 200 m;
Special lengths and special
codings for lengths greater
than 150 m (see chapter 14)
0 … 5 m, 0 … 10 m,
0 … 20 m, …,0 … 150 m;
Special lengths and special
codings for lengths greater
than 150 m (see chapter 14)
Tape tolerance
1 mm per meter 1 mm per meter
NOTICE
Twin tapes on request
 Twin tapes can be ordered on request (see chapter 14).
Manufacturing process Filmsetting
Surface protection Polyester, matt
Base material Polyester film, affixed without silicone
Adhesive Acrylate adhesive
Adhesive thickness 0.1 mm
Adhesive strength (average values) On aluminum: 25 N/25 mm
On steel: 25 N/25 mm
On polycarbonate: 22 N/25 mm
On polypropylene: 20 N/25 mm
Recommended processing temperature 0 °C … +45 °C
Ambient temperature -40 °C … +120 °C
Dimensional stability No shrinkage, tested according to DIN 30646
Curing Final curing after 72 h;
the BPS can detect the position immediately after the BCB
is affixed.
