Basic configuration
Leuze electronic BPS 300i 49
8 Basic configuration
The BPS is configured only via the webConfig tool (see chapter 9).
8.1 Configuring RS 232/RS 422 interface
8.1.1 General information – RS 232/RS 422 interface
The BPS 300i features an integrated RS 232 interface and an integrated RS 422 interface. Both interfaces
are contacted via the HOST / BUS_IN connection; see chapter 7.5.2 "RS 232/RS 422 (HOST / BUS IN)".
The RS 232 interface is active on delivery. Alternatively, the RS 422 interface can be activated. The
currently active interface is indicated in the display.
The baud rate for serial communication is set via the webConfig tool: 4,800 … 115,200 baud.
Factory settings of the interface parameters
• Transmission standard:
RS 232
Value range: RS 232, RS 422
• Baud rate: 38,400 baud
Value range: 4,800 … 115,200 baud
• Data format: 8N1
Value range: 8N1, 8E1, 8O1, 8N2
• Handshake (only for RS 232): none
Value range: none, RTS/CTS
• Output cycle: 4
Value range: 1 … 30 ms
Setting the configuration of the interface
 Set the parameters for the RS 232/RS 422 interface via the webConfig tool.
CONFIGURATION > COMMUNICATION; see chapter 9.3.2 "CONFIGURATION function"
8.2 Configuring the switching inputs/outputs
 Set the configuration of the switching inputs/outputs via the webConfig tool.
CONFIGURATION > DEVICE; see chapter 9.3.2 "CONFIGURATION function"
8.3 Configuring the resolution for the position value
 Set the parameters for the resolution during position measurement via the webConfig tool.
CONFIGURATION > OUTPUT; see chapter 9.3.2 "CONFIGURATION function"
8.4 Configuring velocity monitoring with switching output
 Set the parameters for velocity monitoring via the webConfig tool.
• Switching output function: CONFIGURATION > DEVICE > Switching inputs/outputs; see
chapter 9.3.2 "CONFIGURATION function"
• Velocity limit values:
CONFIGURATION > DATA PROCESSING > Velocity > Monitoring; see
chapter 9.3.2 "CONFIGURATION function"
NOTICE
Activation/deactivation/configuration of the interface with the webConfig tool!
 The RS 232 or RS 422 interface can only be activated, deactivated and configured via the webConfig
tool; see chapter 9.3.2 "CONFIGURATION function".
