Leuze BPS 300i - Mounting with the BTU 0300 M-W Mounting Device

Mounting and installation
Leuze electronic BPS 300i 40
1 Reading distance
2 Reference point for the bar code position
3 Scanning beam
Figure 6.8: Beam exit
6.2.3 Mounting with the BTU 0300M-W mounting device
Mounting the BPS with a BTU 0300M-W mounting device is intended for wall mounting. For ordering infor-
mation see chapter 14; for dimensioned drawing see figure 13.9.
