Basic configuration
Leuze electronic BPS 300i 52
Table 8.4: Response of the BPS
Response telegram for commands 0xF8 and 0xF9
In the response telegram to commands 0xF8 and 0xF9, the BPS transfers the available status information
and the requested data in a ten-byte length.
Table 8.5: Response of the BPS
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 BCB_DIR READY IO2 IO1 0 0 0 0
1 READY QUALITY SLEEP MIS DIAG OUT ERR
2 P31 P30 P29 P28 P27 P26 P25 P24
3 P23 P22 P21 P20 P19 P18 P17 P16
4 P15 P14 P13 P12 P11 P10 P09 P08
5 P07 P06 P05 P04 P03 P02 P01 P00
6 XOR XOR XOR XOR XOR XOR XOR XOR
Data output is the same for interfaces RS 232 and RS 422.
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 BCB_DIR READY IO2 IO1 ADR ADR ADR ADR
1 READY QUALITY SLEEP MIS DIAG OUT ERR
2 P31 P30 P29 P28 P27 P26 P25 P24
3 P23 P22 P21 P20 P19 P18 P17 P16
4 P15 P14 P13 P12 P11 P10 P09 P08
5 P07 P06 P05 P04 P03 P02 P01 P00
6 V15 V14 V13 V12 V11 V10 V09 V08
7 V07 V06 V05 V04 V03 V02 V01 V00
8 XOR XOR XOR XOR XOR XOR XOR XOR
