Technical data
Leuze electronic GmbH + Co. KG BPS 37 12
4.2 LED indicators
An internal LED indicates in the reading window whether or not the supply voltage is applied.
4.3 Dimensioned drawings
BPS 37 S M 100 / BPS 37 S M 100 H
Figure 4.1: BPS 37 dimensioned drawing
NOTE
Two models of the BPS 37 are available:
BPS 37 S M 100without optics heating, UL approval
BPS 37 S M 100 Hwith optics heating, no UL approval
Top viewRear view
