Accessories/order codes
Leuze electronic GmbH + Co. KG BPS 37 14
5 Accessories/order codes
5.1 Accessories
Table 5.1: Accessories/order codes
5.1.1 Connection units / connector hood
MA 4.7/MA 4D.7 connection unit
The connection units MA 4.7/MA 4D.7 are used to simplify the electrical installation of the BPS 37. They
have the following advantages compared to the installation of the BPS 37 as a stand-alone device:
• Terminals for switching inputs and outputs, including voltage supply
• 9-pin sub-D plug for service interface
• Operating mode switch: service operation/normal operation
• Code types - changeover switches binary/gray
• Rotary switch for setting the resolution
• Parameter memory for the BPS - the BPS can be exchanged without the need for reconfiguration.
• Display (MA 4D.7 only)
NOTE
Products from Leuze electronic GmbH & Co KG can be ordered from any of the sales and
service offices listed on the back page of this operating manual.
Designation Order no. Short description
MA 4.7 50037324 Connection unit for BPS 37 with parameter memory
MA 4D.7 50037325 Connection unit for BPS 37 with parameter memory and display
MS 37 103 50107684 Modular connector hood for BPS 37 with M12 connection tech-
nology
BT 56 50027375 Mounting device featuring dovetail for rod
KB 031-3000 50035355 Interconnection cable between BPS and MA, length: 3 m
NOTE
The connection units are described here in brief only. For further information regarding the
connection units please refer to the relevant data sheets
