Technical data
Leuze electronic GmbH + Co. KG BPS 37 13
MS 37 103
Figure 4.2: MS 37 103 dimensioned drawing
4.4 BPS 37 reading field curve
Figure 4.3: BPS 37 reading field curve
MS 37 103
A = BPS 37
all dimensions in mm
Note!
The BUS OUT and SW IN/OUT
connections are sealed with caps upon de-
livery.
A
-80
-60
-40
-20
0
20
40
60
80
0
25 75 125 17550 100 150 200
250
225
Reading distance in mm
Reading field width [mm]
BPS 37
Working range
