Installation
Leuze electronic GmbH + Co. KG BPS 37 19
Figure 6.2: Beam exit on the BPS 37
Mounting location
 When choosing the mounting location, observe the following:
• maintaining the required environmental conditions (humidity, temperature),
• possible soiling of the reading window due to liquids, abrasion by boxes, or packaging material resi-
dues.
• lowest possible chance of damage to the scanner by mechanical collision or jammed parts.
Application example
Figure 6.3: Application example
Minimum distance
(see scanning curve)
002812
0
0
2
8
1
2
0002812
0002812
0002812
0002812
