LevelOne GEP-2841 - List of Accessories

S/N
Indicator
Status
Description
①
Power
Light on
Power on
Light off
No power
②
PoE
Light on
PoE power in
Light off
PoE without power
③
1000M
Light on
The current operating rate is 1000Mbps
Light off
The current operating rate is 10 /
100Mbps or the link is not connected
④
Link/Act
Light on
The link is connected
Light flash
The port has data transceiver
Light off
the link is not connected
List of accessories
l Master unit
l Power cord
l Quick Installation Guide
l L-shaped bracket and other
l Rubber Feet
Installation guide
For the safe installation and operation of the switch, it is recommended that you!
1. Check that the power cord is securely wrapped around the AC power connector"
2. Ensure proper heat dissipation and ventilation around the switch"
3. Do not stack heavy objects on the switch"
Mounting to rack
1. Check the grounding and stability of the frame"
2. Install the two L-shaped brackets in the accessories on both sides of the switch panel
and fix them with the screws provided in the accessories, as shown in Figure 2-1"
3. Place the switch in the appropriate position in the rack and supported by the bracket"
Fix the L-shaped bracket on the guide grooves fixed at both ends of the rack with screws
to ensure that the switch is stably and horizontally installed on the machine, as shown in
