LevelOne GEP-2841 - Port Isolation

Figure 0-18
As shown in Figure 3-20 below, Rx is selected for the direction (messages sent by the
equipment connected to the switch are received for the switch port), 1 is selected for the
mirror port, and 2 is selected for the mirrored port"
Figure 0-19
Port Isolation
Figure 0-20
The port isolation function can realize the layer-2 data isolation between different ports and
cannot communicate with each other. By default, all ports are not isolated"
Port
!
Set object port"
