2. Hardware Installation
Before installation, please make sure all of peripherals and computers have been turned off.
This example of installation is based on KVM-0831 and the procedure of KVM-1631 is the
same.
Step 1 Rack Mounting
KVM-0831 / KVM-1631 can be mounted in a standard 19-inch equipment rack or on a
desktop. To mount to a rack, attach the brackets to the device using the screws provided in
the rack-mount Kit.
Step 2 Local Console
Connect the monitor to the HDDB-15 female port of the local console ports on the back of
the KVM.
Step 3 USB Keyboard
Connect an USB keyboard to the KVM Switch.
