23
6. Technical Specification
Model No. KVM-0831 KVM-1631
PC Port 8 16
PC Port Connector
(All Female Types)
VGA HDDB 15pin
Local Console Port
(All Female Types)
USB Keyboard (USB Type A)
USB Mouse (USB Type A)
VGA HDDB 15pin
Remote Console
Expansion Slot
ACC-1000 KVM Cat5 Console module (Optional)
Daisy Chain Port
Connector
(All Female Type)
VGA HDDB 15pin
PC selection On Screen Display Menu, Hot Key, Push Button
PC Port LED 8 16
Bank 7 segment LED 3
On Screen Display Yes
Scan Intervals 5~99 Sec.
Keyboard Emulation PS2 or USB
Mouse Emulation PS2 or USB
VGA Resolution 1920X1440
Bandwidth 200MHz
Daisy Chain MAX Level 8 levels
MAX PC Connection 120* 128
Housing Metal
KVM Switch Power
Adapter
DC 12V, 1.0A
Operation Temperature 0~50℃
Storage Temperature -20 ~ 60℃
Humidity 0~95%, Non-Condensing
Weight (kg) 2.0kg 2.3kg
Dimension (mm) 445(L) X 160(W) X45 (H)
* Cascading 1 KVM-0831 + 7 KVM-1631 together
