15
OSD Menu
OSD Menu provides a menu-driven interface to control the KVM switch.
This OSD Menu has four types of display screens:
1. Login Window --- When powering on this KVM switch, it will prompt a login window
and ask for user name and password. This KVM system can setup one SUPERVISOR
and eight USERs. SUPERVISOR can access to all OSD functions. USER can access
to PORT NAME and PORT SEARCH only.
2. Status screen --- after the log in the Status screen will show up to display the current
port settings and Hotkey type.
3. Port Name --- this menu displays port status, and you can switch to other port right
here.
4. Main Menu --- there are eight menus to operate. They are listed as below:
MAIN MENU Function
01 LANGUAGE OSD language selection
02 PORT NAME EDIT PORT NAME modification
03 PORT SEARCH Quick searching by port name
04 USER SECURITY Change password
05 ACCESS LIST Define user access authority
06 HOTKEY Change Hotkey
07 TIME SETTINGS Modify auto-SCAN time interval
08 OSD MOUSE Modify OSD MOUSE speed
