14
Example #1 – To bring up the OSD overlay window, press “Caps Lock”, “Caps Lock”,
and the “Space Bar”. Immediately, the OSD overlay screen will appear. The
superimposed menu screen is generated by the KVM switch, and does not affect your
computers or software function in any way.
Caps
Lock
Caps
Lock
please enter next key in
2 seconds in the
Hotkey sequence
Space Bar
Example #2 – To switch to Bank 1 Port1, press “Caps Lock”, “Caps Lock”, and “1”, “0”,
“1”.
Lock
Caps
please enter next key in
2 seconds in the
Hotkey sequence
a
Lock
Caps
1
0 1
Actually there are two methods to bring up the OSD overlay window.
1. Activate OSD by press Hotkey --- press Hotkey twice then press Space bar.
2. Activate OSD by Mouse ---
Press and hold the left button of the mouse and hit the Esc key to show the Status
screen.
Press and hold the right button of the mouse and hit the Esc key to bring up the Main
Menu.
