8
Step 4 USB Mouse
Connect an USB mouse to the KVM Switch.
Remote Console (Optional Module ACC-1000)
Extending your PC console up to 300 meters away:
(1) Make sure that the Cat.5 cable is straight through type.
(2) Plug one end of Cat.5 cable into the remote console port of KVM switch and the other
end of Cat.5 cable into the RJ-45 port of KVM-9007 Cat.5 receiver.
(3) Connect keyboard, mouse and monitor to the Keyboard/Mouse port and Monitor port
of KVM-9007.
(4) Connect Local PC to KVM-9007 by using the HDDB-15 to the VGA+PS/2+USB cable
(5)
ACC-1000
KVM-9007
To Next Page
