LevelOne KVM-0831 User Manual

17
Port Name
The first page shows the current port name and the selected port, and the operation hint.
The selected
The selected
O
p
eration Hint
User
A
uto-Scan
Firmware
OSD Function Key Description
F1 Go to the Main Menu
F2
To log out the OSD. If Security is enabled it will
show up the Login window waiting for
username and password. If Security is disabled
it will show up the Status window
F3 Previous Menu
Enter Switch to the selected port
↑ / ↓
Select the port (press Enter to switch)
PgUp Previous Bank
PgDn Next Bank
Esc Exit
1 Show ports 01 ~ 08
2 Show ports 09 ~ 16
3 Show ports 17 ~ 24
4 Show ports 25 ~ 32
