i Series e Users Guide Page 15 of 35
LIT-31903-00
3.0 i series e Hand Held Terminal
There are two operating modes for the i series e Hand Held Terminal (HHT):
Local Mode (HHT plugged into the front connector of the control module)
Remote Mode ( HHT connected through the Backplane Terminal Block TB2 )
Local Mode is used for the following purposes:
Rack Configuration
• To view the software version of the control module.
• To configure and view the control module position and rack number
• For remote mode operation (this is not the thumbwheel setting)
• To view the line frequency setting
• To configure and view the incoming line power voltages,
• To configure and view the DMX hold time setting
• To configure and view the line regulation mode.
• To manage security features
• To configure or reset to factory default configuration
• To set global parameters (applies to all dimmer positions)
Dimmer Configuration
• To view and edit the control module custom patch
• To softpatch any DMX-512 dimmer channel to any dimmer position in the rack.
• To softpatch any Luma-Net control channel to any dimmer position in the rack.
• To view dimmer control levels and HTP source on a dimmer per dimmer basis.
• To view and edit maximum and minimum levels
• To view and set unregulated non-dims.
• To force a dimmer to a control level and bypass all other control inputs (dimmer check)
• To view and setup fluorescent dimming
Control Module Status
• To view control module status (OK, emergency, overtemp warning, backplane error)
• To view the DMX-512 input status
• To view the analog inputs status
• To view the backup input status
• To view the panic input status
• To view the Luma-Net input status
Remote Mode is used for the following purposes:
• Recording backup looks from the DMX-512 signal input
• Playing backup looks
Important Note: Only one HHT may be plugged into the HHT wiring system at a time.
