i Series e Users Guide Page 30 of 35
LIT-31903-00
4.12 Record Look Menu – Are You Sure?
RECORD LOOK # = 01
FADE TIME = 005.0
ARE YOU SURE?
[BACK]
7. At this point, there are two options: [ENTER] to record the look, or [BACK] , which will return the
cursor to the fade time field. An [ENTER] selection will snapshot record the current active scene on
the DMX-512 port(s) and write it to the EEPROMS on the backplane.
8. Repeat steps 3 through 7 for each backup look that is to be stored in the racks. The backup looks will
auto-increment on playback, so it is recommended that the backup looks are recorded in the sequence
they are to be played back. The backup looks may be played out of sequence, but it requires more
concentration than just pressing the [GO] key.
Please note that this DMX snapshot procedure is also detailed in section 2.3 of this manual. When you are
finished recording all of the backup looks, with the cursor blinking on the most significant look number digit,
press the [BACK] soft key. The following main menu will be displayed:
4.13 Main Remote Menu
i series e V1.1
REMOTE MODE
rec / goto look active
Please note that “ V1.1” is a bug. The display should read “ V1.2” for version 1.2 software, but it doesn’t.
The correct version is displayed, however, on the local mode main menu display on the front port of each
control module. This is the menu position that the HHT should be left in, when finished using either the
[REC LOOK] or [GO TO LOOK] menus.
4.2 i series e HHT – Remote Mode – Go To Look
To play backup looks, either plug in the HHT into the remote mode port, and press [GO TO LOOK] , or from
the following main menu :
