i Series e Users Guide Page 20 of 35
LIT-31903-00
3.3 i series e HHT – Local Mode – Edit Config Rack
To change rack configuration options for this control module, you first enter configuration mode and then
page through the screens and make your changes. The configuration screens are laid out the same as the
display rack screens as discussed in chapter 3.2. To enter rack configuration mode, follow the following
procedure:
1. From the main local menu, press the (RACK) softkey
(if you are not at the main local menu, either use the (BACK) button to return, or simply unplug and
re-plug in the HHT)
2. Press (RACK)
3. Press [CONFIG RACK]
E
D
I T
R
A
C
K
C
O
N
F
I G
E
n
t e
r S
e
t u
p
C
o
d
e
X
X
X
X
[ B
A
C
K
]
4. Enter the password / setup code (factory default is 0000)
The Config Rack menu should now be visible on the LCD Display.
Config Rack – Main Menu
E
D
I T
R
A
C
K
#
#
0
1
U
P
P
E
R
C
O
N
T
R
O
L
M O
D
U
L
E
1
2
0
V
O
L
T
A
C
S
Y
S
T
E
M
[ M O
R
E
] [ H
E
L
P
] [ B
A
C
K
]
The difference between configuration mode and display mode is that in configuration mode you have a
cursor which is blinking at it’s current location. To move from field to field within the configuration screens,
press the [ENTER] button. To change values, either use the [UP][DOWN] buttons to select from a list or
enter the numeric value with the number pad.
Using the (MORE) and (BACK) buttons you toggle through the same menu’s as when in display mode,
however, you’re able to change values using the [ENTER] button to move between fields, and [UP][DOWN]
or the keypad to change values.
When in configuration mode, if you make a mistake when entering a value, press the (BACK) soft key. This
works like an ‘undo” and will not save your changes. Alternatively, pressing the enter or (MORE) key will
save your changes.
Two additional screens are available when in rack configuration mode which are not available in rack display
mode. These screens are accessed by pressing the (MORE) button past the cutoff level screens.
