6.0 i series e Specifications
Rack Capacity (96/48) 96/48 Circuits, 20 (120V) or 25A (240V) Amp max. per
circuit
48/24 Circuits, 50 Amp max. per circuit
Dimensions 84.5” H x 16.5” W x 24” D
50” H x 16.5” W x 24” D
Weight i96 rack:
330 lbs (151 kg) Empty
650 lbs (294 kg) Full
i48 rack:
175 lbs (80 kg) Empty
340 lbs (155 kg) Full
1,000A Cross Bussing - 29 lbs. per section
2,000A Cross Bussing - 58 lbs. per section
3,000A Cross Bussing - 90 lbs. per section
Amp Traps - 31 lbs. per section
Conduit Entry Areas See section 4
Maximum Fan Noise Rating 71 dBA
Ambient Operating Temperature 0°C (32°F) to 40°C (104°F)
Maximum Operating Humidity 90% without condensation
Maximum Feeder Size 800 Amp (400A for i48 rack)
Nominal Input, 120V Circuits 120/208V, 3Ø, 4W, 50/60Hz or
120/240V, 1Ø, 3W, 50/60Hz
Nominal Input, 240V Circuits (foreign service) 240/415V, 3Ø, 4W, 50/60Hz or
240/480V, 1Ø, 3W, 50/60Hz
Phase-to-Neutral Operating Voltage 100-127V ± 10% or 220-240V ± 10%
Operating Frequency 47-63Hz
Rack Enclosure NEMA type 1 for indoor use only
(utilizer dans un edroit a l’arbi)
Specifications: Belden Cable 9829 and 9830
24 Gage; Stranded Conductors (7x32); Polyetheylene Insulated; Beldfoil 100% Shield Coverage; 30V; 80°C;
Tinned copper; twisted pairs
Trade No No. of
Pairs
Nominal D.C.R Nom. Imp.
(ohms)
Nom. Vel. of
Prop.
Nominal
Capacitance
Cond. Shield * pF/ft. ** pF/ft.
9829
NEC CM
CSA
PCC FT 1
2 24 (7x32)
24.0Ω/M’
78.7Ω/km
3.71Ω/M’
12.17Ω/km
100 66% 15.5 27.5
9830
NEC CM
CSA
PCC FT 1
3 24 (7x32)
24.0Ω/M’
78.7Ω/km
3.86Ω/M’
12.66Ω/km
100 66% 15.5 27.5
Note: Belden 9830 may be substituted for Belden 9829
