i Series e Users Guide Page 17 of 35
LIT-31903-00
diagnostic LED on the control module. Does the LED flicker very rapidly ? If so, then your hand held
terminal is configured properly, therefore skip down to the next paragraph. If it blinks slowly (about once per
second) then your hand-held remote is not configured properly for operating with version 1.2 or later
software, so please call (503) 404-5500 and ask to speak to a tech services representative. They will walk you
through the i series e HHT configuration procedure.
You should now be at the main local menu which is:
Main Local Menu
i S
E
R
I E
S
E
1
. 5
L
O
C
A
L
R
A
C
K
0
1
^
C
M 6
0
H
Z
V
A
=
1
2
4
V
B
=
1
2
5
V
C
=
1
2
2
[ R
A
C
K
] [ S
T
A
T
] [ D
I M S
]
Maybe the control module's not configured as expected. Parameters like the rack number, control module
position, and line voltage range are set later in this manual. The following outline details the display values
and their functional descriptions.
Display Description
i series e Product Identification.
V1.5 Current software version. If it reads V1.0 or V1.1, then you need a software upgrade
before proceeding further.
Rack// Default rack number. If no one has set up the HHT configuration before, then this is what
you'll see. Don't worry. It's only really applicable in remote mode for the HHT to operate
properly. If someone has already configured the rack it will probably display RACK 01,
RACK 02 or something with a logical number association.
^CM or Upper Control Module
vCM Lower Control Module
50hz or Power Line Frequency. Determined by software.
60hz
VA=124V Don't worry if the line voltage setting is displayed in the wrong range for now.
VB=125V It won't hurt anything. The control module doesn't care if it is operating
VC=122V within the range of 90-135VAC or 190-260VAC. The Voltage display range is set by a bit
that is read in from the eeprom on the backplane.
[RACK] [S1]softkey function. Go to rack configuration menu
[STAT] [S2]softkey function. Go to status Menu
[DIMS] [S3]softkey function. Go to dimmer configuration menu
