Hazardous voltage may be present.
In order to avoiding fluid spills shorting voltages within the converter,
place it in a spill protected environment (for example protected
electronic cabinets).
If explosive flammable gases are present, place the converter in an
explosion-proof cabinet.
1. The converter shall be installed in a spill protected cabinet.
2. Assure that sufficient ventilation is provided in order to avoid exceeding the allowed ambient
temperature and humidity range:
➔ Temperature range: 0 – 50 °C (32 – 122 °F)
➔ Humidity range: 30 - 85% R.H. (no condensation)
3. Bring the fixation bars in to un-lock position (see Figure 11).
4. If multiple converters are used (see Figure 17b) stack them together.
5. Attach the connector box (see Figure 17a)
6. Attach the termination box (Figure 17a) and fix it by pushing the fixation bars of the
termination box (see Figure 17b and Figure 11) to the inside.
7. Bring the fixation bars into the locked position (see Figure 11 and Figure 17b)
8. Mount the whole stack on a DIN rail following the same steps as described in Figure 16 for
the single channel converter LFC-1C.
