2.4 Overview of Parameter Configuration
Table 4 shows the standard (“Default”) and possible parameter configurations of the clamp-on flowmeters.
This user manual is dealing with the standard configuration. For setting up other configurations the Levitronix
®
Service Software is needed. Consult the Levtronix

Service Software manual for more detailed description.
Block
Parameter
Option/Range
Default
Note
Basic
Sensor size
LFSC-ixxX
Automatically set.
xx = 06/10/16/19/25/35
Full scale
0.01 – 160 L/min
Automatically set.
Default values are:
LFSC-i06X=1 lpm LFSC-i10X=20 l/min LFSC-i16X=20 lpm
LFSC-i19X=50 lpm LFSC-i25X=80 lpm LFSC-i35X=160 lpm
Damping time
0 – 25 s
2.0 s
Low-pass filter with
T
f
dB

=
 2
1
3
Low cutoff
0.0 – 25.0 %
2 %
Flow cut to 0 below this percentage of full-scale
If cutoff 0% is chosen, negative flow becomes visible
Kinematic Viscosity
(= Dynamic Visc. / Density)
Not implemented
for LFSC-iX series
Not implemented
for LFSC-iX series
Not implemented for LFSC-iX series sensors.
Analog output
settings
Analog output setting
4 – 20 mA or
0 – 20 mA
4 – 20 mA
--
Digital input
settings
Digital input
Volume counter reset
Zero adjust
Set Volume Counter to zero
Zero adjust
--
Digital output
settings
Digital output 1
Flow alarm High
Flow alarm Low
Vol. counter alarm H
Vol. counter alarm HH
Vol. counter Pulse
Measurement Error
Flow as Frequency
Bubble detect
Custom Output
Measurement
Error
- Upper flow limit detection
- Lower flow limit detection
- Flow volume detection first value (one-time)
- Flow volume detection second value
- Pulse per volume
- Error signal (empty sensor etc.)
- Flow as Frequency output (100% of full-scale = 1 kHz)
- Bubble detected signal
- Bits of equipment status can be OR-ed on the output
Digital output 2
Flow alarm High
Flow alarm
Hysteresis (Flow alarm)
0 – 20 %
0 %
Can be used to get tolerance to noise.
Alarm high
0 – 125 %
105 %
Alarm setting In percentage of full-scale.
Contact type
N.O. = normally open
N.C. = normally closed
N.O. = norm. open
-
Alarm low
-10 – 125 %
- 5 %
Alarm setting In percentage of full-scale.
Contact type
N.O. = normally open
N.C. = normally closed
N.O. = norm. open
-
Volume counter
settings
Volume counter enable
(activation box)
activated, not activated
not activated
These are settings for volume detection (integration of
flow).
Has to be active for the options “ Vol. Counter Alarm H”,
“Vol. Counter Alarm HH” and “Vol. Counter Pulse”.
Volume counter base unit
1 mL, 1 L, 1 m3
1 mL
Multiplier factor
0.01, 0.1, 10, 100, 1000
0.1
Volume counter pulse length
0.5, 50, 100ms
0.5 ms
Volume counter alarm enable
(activation box)
activated, not activated
not active
-> Settings for one-time volume detection.
-> Volume = “Volume unit” x “Multiplier factor” x “Vol.
Counter Alarm H“ value”
-> Has to be active for the options “Vol. Counter Alarm
H”, “Vol. Counter Alarm HH”.
Value (Volume counter alarm H)
0 – 999999
--
Contact type (H)
N.O. = normally open
N.C. = normally closed
N.O. = norm. open
Value (Volume counter alarm HH)
0 – 999999
--
Contact type (HH)
N.O. = normally open
N.C. = normally closed
N.O. = norm. open
Measurement
Error Settings
Instant Measurement Error Ignore
Time
0-99 s
10s
During this time instant measurement errors are ignored.
If an instant measurement error stays active for longer
time than this time, measurement error arises.
Flow Level on Measurement Error
0%, -25, 125%
Hold
0 %
Signal level of analog output and flow, when
measurement error arises
Bubble
Detection
Settings
Bubble Detect Hold Time
Not implemented
for LFSC-iX series
Not implemented
for LFSC-iX series
Not implemented for LFSC-iX series sensors.
Table 4: Overview of parameters
