Lexicon Lambda User Manual

32
Specifications
SPECIFICATIONS
Microphone Inputs: (2) Female XLR Pin 2 Hot
Input Impedance: 600 Ohms balanced
Phantom Power: +48 Volt
GAIN: +44 dB
EIN: −120 dB A-weighted @ 44dB gain (150 Ohm source impedance)
Maximum Input Level: 6.5 dBu
Frequency Response: +0, −0.5 dB 20 Hz - 20 kHz, ref. 1 kHz
THD+N: <.005%, 20 Hz - 20 kHz
Insert Inputs: (2) 1/4" TRS
Send Level (tip): +10 dBu maximum
Maximum Return Level (ring): +11 dBu maximum
Line Inputs: (2) 1/4" TRS balanced or unbalanced
Input Impedance: 20 kOhm balanced, 10 kOhm unbalanced
Maximum Input Level: +13 dBu
Frequency Response: +0, −0.5 dB 20 Hz - 20 kHz, ref. 1kHz
THD+N: <.009% A/D, 20 Hz - 20 kHz
Instrument Input: (1) 1/4" mono jack
Input Impedance: 1 MOhm unbalanced
Maximum Input Level: +8.5 dBu
Frequency Response: +0, −1 dB 20 Hz - 20 kHz, ref. 1 kHz
THD+N: <.0125% A/D
Line Outputs: (2) 1/4" TRS balanced or unbalanced
Level: +16 dBu maximum
Impedance: 1 KOhm Balanced, 500 Ohm Unbalanced
Headphone Output: (1) 1/8" stereo jack 20 mW per channel at 50 Ohms
MIDI Interface: 5 pin DIN connectors for MIDI in and MIDI out
Sample Rate: 44.1 kHz or 48 kHz (determined by computer application)
Dynamic Range: A/D (24 Bit) 96 dB typical, A-weighted, 20 Hz - 20 kHz
D/A (24 Bit) 100 dB typical, A-weighted, 20 Hz - 20 kHz
A/D/A (24 Bit) 95 dB typical, A-weighted, 20 Hz - 20 kHz
Power Requirements: USB powered
Dimensions: 6.5 x 6.7 x 3.4
Weight: 1.92 lbs.
Lexicon engineers are constantly working to improve the quality of our products.Specifications are therefore
subject to change without notice.

Lexicon Lambda Specifications

General

Type	USB Audio Interface
Phantom Power	Yes
Sample Rate	44.1kHz, 48kHz
Bit Depth	24-bit
Mic Preamps	2
USB	USB 1.1
Inputs	4 (2 XLR/TRS combo, 2 line)
MIDI I/O	Yes (1 in, 1 out)
Outputs	2 x TRS
