Lexicon MC-12HD - Trigger Setup

MC-12HD Setup
3-73
TRIGGER SETUP
The TRIGGERS option prompts you to select trigger output connector 1 or 2. The
MC-12HD includes three 12V DC trigger output connectors labeled PWR (power), 1, and
2. The PWR connector cannot be configured because its trigger output connector is
activated and deactivated when the MC-12HD is activated and deactivated or placed into
standby. The other connectors can be configured for remote or program operation.
Selecting TRIGGER 1 or TRIGGER 2 displays the corresponding TRIGGER SETUP menu, to
configure the selected trigger output connector. The TRIGGER SETUP menu shown at the
right is used as an example. The parameters on the left side of the TRIGGER SETUP menus
are identical regardless of whether TRIGGER 1 or TRIGGER 2 is selected. The parameter
settings on the right side are adjustable. The TRIGGER SETUP menu (shown on this page)
indicates factory default parameter settings for both connectors.
All TRIGGER SETUP menu parameters – except the REMOTE ONLY parameter – are considered program operation parameters.
Parameter Default Setting Possible Settings
REMOTE ONLY ON ON, OFF
Program Operation OFF ON, OFF
