Getting Started
MPX 110
1-5
4. Output
Sets analog output levels.
5. Effects Lvl/Bal
Sets effect level in SINGLE programs or effect
balance in DUAL programs.
6. Edit LED
Lights to indicate that a program has been modified
but not stored, and flashes to indicate MIDI activity.
(See page 2-4 for more information about editing
programs.)
7. Adjust
Controls the most relevant parameters for the
selected program variation.
8. Bypass
Mutes or bypasses the incoming signal, depending
on the setting of the System Mode parameter
Bypass. Press and hold for 2 seconds to access
System Mode parameters.
9. VARIATION
Selects program variations when the PROGRAM
knob is set to a SINGLE or DUAL program. Selects
memory locations for storing User programs when
the PROGRAM knob is set to User.
10. PROGRAM
Selects SINGLE, DUAL, or User programs.
11. Store
Activates the store function for User programs. When
pressed with Tap, activates MIDI Learn Mode.
12. Tap
Flashes to indicate that a tempo-based program is
selected. When pressed twice, sets tempo. When
pressed and held, uses input level to determine
tempo. When pressed with Store, activates MIDI
Learn Mode.
