Lexicon MPX 110 User Manual

Getting Started
Lexicon
1-6
1. POWER
Supplies power to the unit. Utilizes a Lexicon 1.9A,
9VAC power pack.
2. FOOTSWITCH
Allows footswitch control of front panel Bypass and
Tap functions. A 1/4 inch Tip/Ring/Sleeve connector
for a momentary contact footswitch is available.
REAR PANEL OVERVIEW
1 3
2 4
5 6
Tip
Ring
Sleeve
Tip Sleeve
Ring
Tap
Bypass
