Program Descriptions
Lexicon
4-20
DUAL PROGRAMS
The DUAL Programs combine Delay with Reverb, or
either Delay or Reverb with Chorus, Flange, or Pitch.
Four routing configurations are used in the variations of
each DUAL program: Dual Stereo (Parallel), Cascade,
Mono Split, and Dual Mono.
Variation knob settings are configured as follows:
• Variations 1 to 6 are arranged in the Dual Stereo
(Parallel) configuration - two stereo effects placed
next to one another to receive and output stereo
audio from both the left and right channels.
• Variations 7 to 10 are arranged in the Cascade
configuration - two stereo effects, one placed after
the other. For example, in Flange-Delay, Flange
passes its stereo signal to Delay.
• Variations 11 to 14 are arranged in the Mono Split
configuration, which is similar to the Dual Stereo
(Parallel) configuration. One effect (Flange) receives
audio from the left input and the other effect (Delay)
receives audio from the right input. Both effects
output stereo audio.
• Variations 15 and 16 are arranged in the Dual Mono
configuration where one effect (Flange) appears on
the left channel only, while the other effect (Delay)
appears on the right channel only.
