Page #75 background imageLoading...
Page #75 background image
MIDI Operation
Lexicon
5-4
PROGRAM CHANGE MESSAGES
LOADING PROGRAMS
Standard MIDI Program Change messages can be used
to load all 240 preset and 16 User programs. The unit
conforms to the use of MIDI Continuous Controller 32 to
execute Bank Select messages. For purposes of this
section, each PROGRAM knob setting selects a “bank” of
16 programs. These banks are numbered as shown in the
table at the right.
When a standard MIDI Program Change message is sent
to the unit on its Program Load channel, Program
Change messages 0 to 15 will load program variations 1
to 16 from the selected program bank. When a Bank
Select message is sent to the unit with Continuous
Controller 32 before the Program Change message, any
one of the 256 programs can be loaded.
For example, the PROGRAM knob is set to Plate, Gate:
Sending Program Change 1 will load the first Plate
program.
Sending Controller 32 with a value of 0 followed by
Program Change 1 will load the first program in the
User bank.
Sending Controller 32 with a value of 1 followed by
Program Change 2 will load the second program in
the Flange-Delay bank.
Sending Controller 32 with a value of 8 followed by
Program Change 15 will load the last Gate program
in the Plate, Gate bank.
Once a bank is selected with the PROGRAM knob, all
subsequent Program Change messages will select
MPX 110 Program Banks
0 User
1 Flange-Delay
2 Pitch-Delay
3 Chorus-Delay
4 Delay-Reverb
5 Flange-Reverb
6 Pitch-Reverb
7 Chorus-Reverb
8 Plate, Gate
9 Hall, Chamber
10 Ambience, Room
11 Tremolo, Rotary
12 Chorus, Flange
13 Pitch, Detune
14 Delay, Echo
15 Special FX
