Use the Edit LED to determine the
current setting of the selected
parameter. See the next page for
more information.
System Mode
Lexicon
3-2
System Mode can be used to configure System Mode
parameters and execute MIDI Dumps. To enter System
Mode, press and hold the front panel Bypass button for
approximately 2 seconds. The Bypass and Store LEDs will
flash slowly to indicate that System Mode is active.
The table on the next page shows System Mode
parameters and functions. The VARIATION knob selects
the desired parameter or function. Settings 1 to 8 select
System Mode parameters. Settings 14 to 16 select MIDI
Dumps.
The Edit LED shows the current setting of the selected
parameter (see the table on the next page). Press the
Store button to toggle the parameter setting. When
VARIATION knob settings 14, 15, or 16 are selected,
press the Store button to execute the selected MIDI
Dump.
When finished, reset the VARIATION knob to its original
setting before System Mode was activated. Otherwise, a
new program will load based on this setting when
System Mode is deactivated. Use the Tap LED to
determine if the VARIATION knob has been
reset; it will light when the knob is set to the last
loaded program.
To exit System Mode, press the Bypass button. The Store
LED will flash quickly to indicate that parameter settings
have changed. (The Store LED will not flash if no changes
were made.)
Descriptions of all System Mode parameters and
functions are available on pages 3-3 to 3-5.
Press the Bypass
button to enter and
exit System Mode.
Use the VARIATION
knob to select the
desired parameter
or function.
Press the Store button to toggle the
setting of the selected parameter or
to execute the selected MIDI Dump.
To Next Page
