Program Descriptions
MPX 110
4-3
GATE
Gated reverbs were created by feeding a reverb, such as
a metal plate, through an analog gate device. Decay
time was set to instant, while hold time varied
duration and sound.
The Gate programs provide a fairly constant sound with
no decay until the reverb is cut off abruptly. These
programs work well on percussion, particularly on snare
and toms. It is recommended to experiment with other
sound sources as well.
VARIATIONs Adjust Tap
9 Straight Gate Duration** –
10 Drum Gate Duration** –
11 Slope Down Duration** –
12 140ms Gate High Cut* PreDelay
(1/32 Note)
13 240ms Gate High Cut* PreDelay
(1/32 Note)
14 340ms Gate High Cut* PreDelay
(1/32 Note)
15 440ms Gate High Cut* PreDelay
(1/32 Note)
16 540ms Gate High Cut* PreDelay
(1/32 Note)
* The Adjust knob functions as a linear control in these variations. See
page 2-2 for more information.
** Audio will be briefly muted when Duration is altered with the Adjust
knob.
