One-dimensional bar codes
43
6–7 Bar Height int 150–600
(dec)
240 (dec)
00 F0 (hex)
Optional
Corresponds to HP #v parameter in
the specified Bar Height units
Note: Values that go beyond the
defined range are appropriately
clipped and set to the minimum and
maximum values.
The default HIBC bar height is 0.4
inches. If byte 5 is default 00 (600
dpi), then the bar height is 240 Bar
Height Units, which is 00 F0 hex.
8 Bar/Space Width
Units
int 0=Default
(1/600” units)
1=1/300”
units
2=1/600”
units
3=1/1200”
units
0 or 2 (dec)
00 or 02 (hex)
Optional
Specifies units for bar and space
widths
9–10 Bar Width #1
(Code 128 bar 1,
or Code 39
Narrow)
int 5–27 (dec) 6 (dec)
00 06 (hex)
Optional
Note: Values that go beyond the
defined range are appropriately
clipped and set to the minimum and
maximum values.
The default HIBC 128 bar 1 and
HIBC 39 narrow bar widths are both
0.01 inches. If byte 5 is default 00
(600 dpi), then the bar width is 6,
which is 00 06 hex.
11–12 Space Width #1
(Code 128 space
1, or Code 39
Narrow)
int 5–27 (dec) 6 (dec)
00 06 (hex)
Optional
Note: Values that go beyond the
defined range are appropriately
clipped and set to the minimum and
maximum values.
The default HIBC 128 space 1 and
HIBC 39 narrow space widths are
both 0.01 inches. If byte 5 is default
00 (600 dpi), then the space width is
6, which is 00 06 hex.
Byte Field name Type Range Default value Description
