One-dimensional bar codes
44
ITF-14
Byte Field name Type Range Default value Description
0–1 Symbology ID int int n/a 103 (dec)
00 67 (hex)
Required
Specifies ITF-14 symbology
2 HRT Location int 0=Default
(No HRT)
1=No HRT
4=Under
5=Above
0 or 1 (dec)
00 or 01 (hex)
Optional
Corresponds to the HP #p
parameter
3 HRT Typeface int 0=Courier
1=SM Gothic
2=SM Unit
3=SM Unit
Condensed
4=Roman
5=OCRB
0 (dec)
00 (hex)
Optional
Corresponds to the HP #h
parameter
Note: When the value given is not
within the defined range, the value is
set to default (Courier).
4 HRT Style int 0=Regular
1=Italic
2=Bold
3=Bold Italic
2 (dec)
02 (hex)
Optional
Specifies the font style used for HRT
Note: Default font style for OCRB is
Regular only.
5 Bar Height Units int 0=default
(1/600” units)
1=1/300”
units
2=1/600”
units
3=1/1200”
units
2 (dec)
02 (hex)
Optional
Specifies units for bar height
dimensions
6–7 Bar Height [int int] Minimum:
307 (dec)
01 33 (hex)
Maximum:
There is no
maximum
value.
756 (dec)
02 F4 (hex)
Optional
Corresponds to HP #v parameter in
the specified Bar Height Units
Note: Values that go beyond the
defined range are appropriately
clipped and set to the minimum
value.
The default BCE ITF-14 bar height is
1.25984 inches. If byte 5 is default
00 (600 dpi), then the bar height is
755.9 (or 756) Bar Height Units,
which is 02 F4 hex.
