c Remove the printer hard disk by pulling it upward to unseat the standoffs.
d Remove the thumbscrews that attach the printer hard disk mounting bracket to the printer hard disk, and then
remove the bracket. Set the printer hard disk aside.
4 Remove the metal cover from the ISP opening.
1
2
Additional printer setup 22
